Power Output
450 x1 watts @ 8 Ω
850 x1 watts @ 4 Ω
1300 x1 watts @ 2 Ω Power measurements are with 120 VAC:
0.15% THD, RMS continuous power,
full audio band (20 Hz - 20 kHz) Class A Power Output
25 Watts, bias switch set to high
10 Watts, bias switch set to low Current Capacity
180 amps, peak
25 watts of pure Class A powerStable with speaker impedance dips below 1ΩBybee Music Rails™ - active high frequency filters for input stageNew John Curl driver stage employs a cascode circuit for greater open loop bandwidth & superior linearityGain switch to select 29 dB or 23 dB gain for optimum compatibility with high gain preamps or extremely efficient speakersR-core transformer for input stage suppresses noise on power line6 massive 33,000 uF Nichicon Gold Tune filter capacitors for output stage22,400 uF input stage power supply filter capacitors, independent of the main power supplyDual CHK Infinium, custom 5-way speaker binding posts for easy bi-wiring Neutrik locking XLR balanced input & loop output jacksVampire 24k gold-plated RCA input & loop output jacksDirect-coupled signal path, no capacitors or inductors in the audio pathJFET input stage, MOSFET driver stage 24 beta-matched 15 ampere, 230V, 60 MHz bipolar output transistors2.1 kVA shielded toroid power transformer with premium H18 grade coreIndependent power supplies for input stage, driver stage & output stageFull power is rated all the way down to 2Hz for unrestricted low-end bassHarris hyper-fast soft-recovery bridge diode rectifiersREL & Nichicon Muse capacitorsDC servo & relay protection circuitsAC turn-on inrush surge protection with relay bypassAutomatic turn-on by 12 V trigger or audio sensing 4 rack space chassis with rear carry handlesRack mount hardware is includedAvailable in silver or blackcijena: 189002,93 kn
cijena je za par monoblokova..
|
