Front panel LCD function display with dimmingAutomatic turn on volume memoryFavorite volume memory with remote control button2-way RS232 w/ exact volume control & feedbackDiscrete commands for all functionsRename inputs to match connected source5 audio inputs including a front panel Aux inputBypass input integrates easily w/ a Sonos Connect® etc.Bass, treble and balance adjustments by remote controlVariable and fixed stereo outputsVariable and fixed mono/subwoofer outputs12dB auto gain offset at front panel AUX to match levels of other sources12V trigger output and rear panel IR input Frequency Response:
10 Hz - 40 kHz, +0/-0.5 dB Total Harmonic Distortion: (20 Hz - 20 kHz)
<0.015% Interchannel Crosstalk:
62 dB at 20 kHz Input Sensitivity :
250 mV = 1 V output
Total gain = 12dB (volume set to 100)
Unity Gain = Volume set to 88
Maximum Output: 3.5 V Input Impedance:
24k Ω Output Impedance:
470 Ω S/N Ratio:
>100 dB, input shorted, IHF A-weighted
>90 dB, input shorted, unweighted DC Trigger Output:
12Vdc, 50ma AC Power Requirement:
5 Watts powered on
0.5 Watts in standby
100 - 250 VAC 50/60 Hz Dimensions
Width: 8.5" (220 mm)
Depth: 10" (254 mm)
Depth: 12" (305 mm) with AC cord and cables connected
Height, with feet: 2" (51 mm)
Height, without feet: 1.75" (45 mm), 1U Weight
Net: 4.0 lbs (1.8 kg)
Shipping: 7.0 lbs (3.1 kg) Rack Mount Accessory
May be Purchased Separately
cijena: 6200,89 kn
|
