Designer’s Introduction
“When I sat down with a blank piece of paper (well actually as this is the 21st century, a blank computer screen) to design the TCT range of amplifiers, I had a long hard look at all the guitar amps that I had designed previously. Even though many of those designs were destined to be what can only be called Classics, I wanted to approach these new amps in a different perspective. Instead of designing under the corporate image of whatever company I was working for at the time, the TCT amps were for the first time “my” amps. This put the image in my mind as “what do I want from an amp, and how do I want it to look”. As a guitar player of many years I have used many different amps, many times different ones hooked up in a multi- amp set up for the different sounds that I needed at the time. This realisation formulated the basic concept and functionality of the direction I needed to go in, something that was simple to use but was as variable as possible. Oh, and sounded great at everything it did as well! The “what do I want it to look like” actually developed pretty quickly – I wanted something that looked classy and stood out from the crowd, something that at the same time was familiar yet unique. For want of a better word “boutique”. I think that the TCT series of Albion amps fulfils my dream and desire with room to spare. Finally “my” amp! I personally love playing these amps and can sit there playing them for hours on end without tiring of them – sometimes to the annoyance of my small team I have to add – I do tend to play very loud at times, and they do have to work!!”
FEATURES IN A NUTSHELL
- Handwired all tube head combo
- 35 watt vacuum tube 2 channel head with 6 6L6 and 4 12AX7 tubes
- 2 preamp channels
- Unique input stage combines the preamp tube with an FET circuit to give lower noise, higher gain, better tonality, and lower microphonics
- Both channels go from clean to scream
- 3 gain stages per channel
- Separate three-band wide range passive EQ, gain, drive, and volume knobs for Channel A and Channel B
- Channel A is pre-EQ and channel B is post-EQ for more tonal options
- Power Amp Response Control – Edge and Feedback
- 33% / 100% power selector
- Mute/active (Standby) switch
- Adjustable solid-state digital reverb
- FX loop with -10 and 0 dBu selector
- Two 1/4 in. speaker output jacks with 8 or 16 ohm options
- Includes footswitch for A/B channel and Reverb On/Off
- High gloss black or dark red trim walnut board with gold Albion Logo
- Birch ply interlocking panels, Black vinyl with grey grille cloth
- Combo model features 80W 12″ custom made Albion G1280 16 ohm loudspeaker
SPECIFICATIONS
- Power: 35W @ 8/16 Ohm
- 12W with power drop switch
- Power valves: Two 6l6
- Preamp valves: Four 12AX7
- EQ controls: Bass, Middle, Treble
- FX Loop level switch: -10dBV / 0dBV
- 33%/100% power selector
- Mute/Active (Standby) switch
- Loudspeaker Output: Two ¼“ jacks wired in parallel
- Loudspeaker impedance selector: 8/16 Ω
- Loudspeaker driver: AMI-G1280 16 Ω
- Loudspeaker power: 80W
- Included Footswitch: Channel A/B switch, Reverb On/Off
- Birch ply interlocking panels, Black vinyl with grey grille cloth
- Dimensions Width x Height x Depth:
- TCT35H W561xH231xD235 mm
- TCT35C W561xH500xD235 mm
cijena: 6999,02 kn
|
