Uncompromising sound quality for overheads, percussion, acoustic guitar, strings and other acoustic instruments Large-diaphragm capsule delivers accurate and natural response Low-profile design permits innovative placement options previously unattainable with a large-diaphragm condenser Robust design for enduring dependability on the road Integral 80 Hz HPF switch and 10 dB pad
AE5100 Specifications Element Signal to Noise Ratio Condenser 83 dB, 1 kHz at 1 Pa Polar Pattern Dynamic Range (Typical) Cardioid 137 dB, 1 kHz at Max. SPL Frequency Response Phantom Power Requirements 20 - 20,000 Hz 11-52V, 3.2 mA typical Open Circuit Sensitivity Switches -36 dB (15.8 mV) re 1V at 1 Pa 10 dB pad; roll-off Impedance Low Frequency Roll-off 150 ohms 80 Hz, 12 dB per octave Maximum Input Sound Level Weight 148 dB SPL, 1 kHz at 1% T.H.D. 5.0 oz (143 g) Noise Output Connector 11 dB SPL Integral 3-pin XLRM-type
Accessories Furnished: AT8471 isolation clamp; 3/8"-16 threaded adapter; AT8136 foam windscreen; protective pouch
|
